Disc Thermostats

Disc Thermostats

Designed to meet the cost, size and features of your application.

If you can't find what you need, please Contact Us or email us: sales@selcoproducts.com to learn more.

Selco’s comprehensive line of highly reliable switches utilize a temperature sensitive bi-metal disc, electrically isolated from the switch. Contacts will close or open on temperature rise when the surface or ambient temperature increases to the snap point of the calibrated bi-metal disc. These disc thermostats are retained by a metal heat conducting sensing cap and are all single pole, single throw non-adjustable switches. To provide flexibility for customer specific applications, we offer a variety of terminal and mounting configurations.

Custom Manufacturing options are available including: brackets, pipe and tube mounts, lead termination, over-molding and epoxy sealing. For details regarding custom disc thermostat assemblies see Custom Manufacturing Capabilities

CA/OA Series
SE (T10) Series
KC/KO Series

Thumbnail

Name

Item #

Description

Ca 130 qc top drop

1/2" Disc Thermostat, US-602SXBVAS45180F30, Opens on rise 180°F ± 5°F, Resets at 150°F ± 11°F, .250" Vertical quick connects, Surface mount bracket, 45deg orientation

Oa 150 top drop

1/2" Disc Thermostat, US-602SXSHAS45200F30, Opens on rise 200°F ± 5°F, Resets at 170°F ± 11°F, Solder terminals, Surface mount bracket, 45deg orientation

Oa 130 st btm drop

1/2" Disc Thermostat, US-602SXBHS2200F30, Opens on rise 200°F ± 5°F, 6Resets at 170°F ± 11°F, .250" Horizontal quick connects, 10-32 Stud mount

Ca 140 qc top drop

1/2" Disc Thermostat, US-602SXBVAS90200F19, Opens on rise 200°F ± 7°F, Resets at 181°F ± 11°F, .250" Vertical quick connects, Surface mount bracket, 90deg orientation

Ca 140 qc top drop

1/2" Disc Thermostat, US-602SXBVAS90185F31, Opens on rise 185°F ± 5°F, Resets at 154°F ± 11°F, .250" Vertical quick connects, Surface mount bracket, 90deg orientation

Ca 140 qc top drop

1/2" Disc Thermostat, US-602SXBVAS90200F30, Opens on rise 200°F ± 5°F, Resets at 170°F ± 11°F, .250" Vertical quick connects, Surface mount bracket, 90deg orientation

Ca 130 qc top drop

1/2" Disc Thermostat, US-602SXBVAS45190F18, Opens on rise 190°F ± 7°F, Resets at 172°F ± 11°F, .250" Vertical quick connects, Surface mount bracket, 45deg orientation

Oa 150 top drop

1/2" Disc Thermostat, US-602SXSHAS45190F30, Opens on rise 190°F ± 5°F, Resets at 160°F ± 11°F, Solder terminals, Surface mount bracket, 45deg orientation

Ca 115 qc top drop

1/2" Disc Thermostat, US-602SXBHQL210F15, Opens on rise 210°F ± 7°F, Resets at 195°F ± 11°F, .250" Horizontal quick connects, Rotating bracket

Ca 140 qc top drop

1/2" Disc Thermostat, US-602SXBVAS90225F20, Opens on rise 225°F ± 5°F, Resets at 205°F ± 11°F, .250" Vertical quick connects, Surface mount bracket, 90deg orientation

Oa 150 top drop

1/2" Disc Thermostat, US-602SXSHAS45220F30, Opens on rise 220°F ± 5°F, Resets at 190°F ± 11°F, Solder terminals, Surface mount bracket, 45deg orientation

Ca 104 st 18 btm drop

1/2” Disc Thermostat, US-602SXBQLSO203F40, Opens on rise 203°F ± 5°F, Resets at 163°F ± 11°F, .250" Quick connects bent to 30deg, 6-32 Stud mount

Oa 170 pcb top drop

1/2" Disc Thermostat, US-602SXPVBO220F30, Opens on rise 220°F ± 5°F, Resets at 190°F ± 11°F, PCB mount

Oa 150 top drop

1/2" Disc Thermostat, US-602SXSHAS45230F30, Opens on rise 230°F ± 5°F, Resets at 200°F ± 11°F, Solder terminals, Surface mount bracket, 45deg orientation

Ca 130 qc top drop

1/2" Disc Thermostat, US-602SXBVAS45210F30, Opens on rise 210°F ± 5°F, Resets at 180°F ± 11°F, .250" Vertical quick connects, Surface mount bracket, 45deg orientation
